| Nomor Bagian | AM-19201200B1TZQW-T11 |
| Merek | AMPIRE |
| Ukuran | 10.1 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1920×1200 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 7S6P |
| Antarmuka | |
| merek panel | AMPIRE |
| ukuran panel | 10.1" |
| resolusi | 1920(RGB)×1200, WUXGA, 224PPI |
| area tampilan | 216.806(W)×135.504(H) mm |
| ukuran garis besar | 243.45(W)×155.2(H) ×7.86(D) mm |
| kecerahan | 850 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 53% NTSC |
| frekuensi | 60Hz |
| berat | - |
| model panel | AM-19201200B1TZQW-T11 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | - |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | Normally Black, Transmissive |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| jenis lampu | 7S6P WLED , 50K hours , Without Driver |
| layar sentuh | PCAP |
| aplikasi | Industrial Outdoor High Brightness |
