| Nomor Bagian | AM-1024600L3HMQW-00H |
| Merek | AMPIRE |
| Ukuran | 10.1 |
| Aplikasi | Industrial Automotiv |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AMPIRE |
| model | AM-1024600L3HMQW-00H |
| ukuran diagonal | 10.1 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×600 [WSVGA] 117PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 222.72(H)×125.28(V) mm |
| garis besar redup. | 235(H)×145.8(V) ×8.85(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare |
| pencahayaan | 550 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) (TM) |
| arah pandangan | - |
| waktu merespon | 4/12 (Typ.)(Tr/Td) |
| sudut pandang | 70/70/70/50 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K 47% NTSC |
| sumber cahaya | WLED [6S6P] , 30K hours , With LED Driver |
| berat | TBD |
| dirancang untuk | Industrial Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
