| Nomor Bagian | TM101JDHP01 |
| Merek | Tianma |
| Ukuran | 10.1 |
| Aplikasi | IA |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | TIANMA |
| model panel | TM101JDHP01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.1 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mode tampilan | SFT, Normally Black, Transmissive |
| daerah aktif | 216.96×135.6 mm |
| garis besar | 229.46×149.1×4.3 mm |
| permukaan | Hard coating |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193150% |
| waktu merespon | 10/15 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 3S11PWLEDWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 40 pins |
| tegangan masukan | 3.3/11.0/23/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplikasi | IA |
