| Nomor Bagian | AM-1024600K7TMQW-T19H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | AMPIRE |
| ukuran diagonal | 7.0 inch |
| format piksel | 1024(RGB)×600 [WSVGA] 169PPI |
| daerah aktif | 153.6(H)×90(V) mm |
| pencahayaan | 425 cd/m² (Typ.) |
| arah pandangan | 6 o'clock |
| sudut pandang | 75/75/70/75 (Typ.)(CR≥10) |
| warna pendukung | 16.7M |
| berat | TBD |
| kecepatan bingkai | 60Hz |
| model | AM-1024600K7TMQW-T19H |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 165.5(H)×104.44(V) ×10.81(D) mm |
| rasio kontras | 700:1 (Typ.) (TM) |
| waktu merespon | 20/20 (Typ.)(Tr/Td) |
| Modus operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED [5S3P] , 30K hours , With LED Driver |
| dirancang untuk | Industrial |
| panel sentuh | PCAP |
| 70WVW1A | SII | 7.0 | 800×480 |
| 70WVW1T | SII | 7.0 | 800×480 |
| A070VW08 V0 | AUO | 7.0 | 800×480 |
| A070XN01 V0 | AUO | 7.0 | 1024×768 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
