| Nomor Bagian | AA090ME01 |
| Merek | Mitsubishi |
| Ukuran | 9.0 |
| Aplikasi | IA |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | Mitsubishi |
| model panel | AA090ME01 1 Compatible model |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 9.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mode tampilan | IPS, Normally Black, Transmissive |
| daerah aktif | 196.8×118.08 mm |
| garis besar | 219×136.2×10 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 900:1 (Typ.) |
| menampilkan warna | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| waktu merespon | 12/12 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 7S2PWLEDWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 6/8-bit), 20 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | IA |
