| Nomor Bagian | WF57STIACDNN0 |
| Merek | Winstar |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | Grayscale |
| Lampu latar | WLED |
| Antarmuka | 8/16-bit |
| merek panel | Winstar |
| ukuran panel | 5.7" |
| resolusi | 320×240, QVGA, 70PPI |
| area tampilan | 115.2(W)×86.4(H) mm |
| ukuran garis besar | 160(W)×109(H) ×7.5(D) mm |
| kecerahan | 1000 cd/m² (Typ.) |
| sudut pandang | - |
| tampilan terbaik di | 12 o'clock |
| menampilkan warna | Grayscale |
| frekuensi | - |
| berat panel | - |
| antarmuka sinyal | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | WF57STIACDNN0 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | Rectangle |
| bukaan bezel | 122.0(W)×92.0(H) mm |
| permukaan | Glare (Haze 0%) |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | - |
| jenis lampu | WLED , Without Driver |
| layar sentuh | Without |
| aplikasi | Industrial |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| G057VGE-T01 | Innolux | 5.7 | 640×480 |
| G057VN01 V0 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G04 | Kyocera | 5.7 | 320×240 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| LTA057A341F | TOSHIBA | 5.7 | 320×240 |
| LTA057A344F | TOSHIBA | 5.7 | 320×240 |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| SP14Q002-A1 | KOE | 5.7 | 320×240 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
