| Nomor Bagian | WEO012864DG |
| Merek | Winstar |
| Ukuran | 0.96 |
| Aplikasi | Handheld & PDA Healt |
| Resolusi | 128×64 |
| Komposisi | OLED , PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Green) |
| Lampu latar | self |
| Antarmuka | 8-bit |
| pabrikan | Winstar |
| ukuran layar | 0.96 inch |
| nomor piksel | 128×64 149PPI |
| area aktif (mm) | 21.738 × 10.858 (H×V) |
| area bezel (mm) | 23.938 × 12.058 (H×V) |
| sudut pandang | - |
| pemandangan bagus di | Symmetry |
| kedalaman warna | Mono(Green) |
| massa | - |
| tingkat penyegaran | - |
| daftar ic driver | Built-in COG SSD1306BZ |
| jenis sinyal | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| sumber tegangan | 3.0V (Typ.) |
| nama model | WEO012864DG |
| tipe layar | OLED , PM-OLED |
| pengaturan | Rectangle |
| garis besar (mm) | 26.7 × 19.26 × 1.81 (H×V×D) |
| perlakuan | - |
| tanggapan | - |
| mode kerja | - |
| lampu latar | self |
| digunakan untuk | Handheld & PDA Healthcare Instruments & Meters |
| layar sentuh | Without |
