| Nomor Bagian | WEA012864DLPP3N00003 |
| Merek | Winstar |
| Ukuran | 0.96 |
| Aplikasi | Instruments & Meters |
| Resolusi | 128×64 |
| Komposisi | OLED , PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Yellow) |
| Lampu latar | self |
| Antarmuka | 4-wire |
| pabrikan | Winstar |
| ukuran layar | 0.96 inch |
| nomor piksel | 128×64 149PPI |
| area aktif (mm) | 21.74 × 10.86 (H×V) |
| area bezel (mm) | 23.94 × 12.06 (H×V) |
| sudut pandang | - |
| pemandangan bagus di | Symmetry |
| kedalaman warna | Mono(Yellow) |
| massa | - |
| tingkat penyegaran | - |
| daftar ic driver | Built-in COG SSD1306BZ |
| jenis sinyal | 4-wire SPI, I²C , 8 pins PIN |
| sumber tegangan | 3.3/5.0/7.5V (Typ.) |
| maks. peringkat | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 80 °C |
| nama model | WEA012864DLPP3N00003 |
| tipe layar | OLED , PM-OLED |
| pengaturan | Rectangle |
| garis besar (mm) | 38 × 28.5 × 4.37 (H×V×D) |
| perlakuan | - |
| tanggapan | - |
| mode kerja | - |
| lampu latar | self |
| digunakan untuk | Instruments & Meters |
| layar sentuh | Without |
