| Nomor Bagian | WEA012864DLPP3N00001 |
| Merek | Winstar |
| Ukuran | 0.96 |
| Aplikasi | Instruments & Me |
| Resolusi | 128×64 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Yellow) |
| Lampu latar | self |
| Antarmuka | 4-wire |
| merek panel | Winstar |
| model panel | WEA012864DLPP3N00001 |
| ukuran panel | 0.96" |
| tipe panel | PM-OLED, OLED |
| resolusi | 128×64, 149PPI |
| format piksel | Rectangle |
| area tampilan | 21.74(W)×10.86(H) mm |
| bukaan bezel | 23.94(W)×12.06(H) mm |
| ukuran garis besar | 38(W)×28.5(H) ×4.37(D) mm |
| permukaan | - |
| sudut pandang | - |
| mode tampilan | - |
| tampilan terbaik di | Symmetry |
| waktu merespon | - |
| menampilkan warna | Mono(Yellow) |
| jenis lampu | self |
| frekuensi | - |
| layar sentuh | Without |
| ic pengemudi | COG Built-in SSD1306BZ |
| berat panel | - |
| aplikasi | Instruments & Meters |
| antarmuka sinyal | 4-wire SPI, I²C , 8 pins PIN |
| tegangan masukan | 3.3/5.0/7.5V (Typ.) |
| lingkungan | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 85 °C |
| IROP018-010-0128064-W | Other | 0.96 | 128×64 |
| L3P10Y-81G00 | Epson | 0.96 | 1400×1050 |
| OEL9M0083-B-E | Other | 0.96 | 128×64 |
| OEL9M0083-R-E | Other | 0.96 | 128×64 |
| OEL9M0083-W-E | Other | 0.96 | 128×64 |
| RGS10096096WR001 | RiTdisplay | 0.96 | 96×96 |
| RGS10128064WR010 | RiTdisplay | 0.96 | 128×64 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HSWEG01 | WiseChip | 0.96 | 128×64 |
