| Nomor Bagian | VTF231BJ02 |
| Merek | BOE |
| Ukuran | 23.1 |
| Aplikasi | Digital Signage Stre |
| Resolusi | 1920×158 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | BOE |
| model panel | VTF231BJ02 |
| ukuran panel | 23.1" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1920×158(RGB), 83PPI |
| format piksel | RGB Horizontal Stripe |
| area tampilan | 585.216(W)×48.158(H) mm |
| bukaan bezel | 587.5(W)×49.8(H) mm |
| ukuran garis besar | 597.2(W)×60.2(H) ×17.1(D) mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 15 (Typ.)(G to G) |
| menampilkan warna | 16.7M 72% NTSC |
| jenis lampu | WLED , 30K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 450g (Typ.) |
| aplikasi | Digital Signage Stretched Bar LCD |
| antarmuka sinyal | LVDS (1 ch, 8-bit) , 30 pins Connector |
| tegangan masukan | 12.0V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
