V420H2-LS2 Rev.C7

V420H2-LS2 Rev.C7
V420H2-LS2 Rev.C7
V420H2-LS2 Rev.C7
V420H2-LS2 Rev.C7 thumb V420H2-LS2 Rev.C7 thumb V420H2-LS2 Rev.C7 thumb
Merek
Innolux
Ukuran
42
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
370
CR
5000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
15342
Spesifikasi

Nomor Bagian V420H2-LS2 Rev.C7
MerekInnolux
Ukuran42
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan370
CR5000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
merek panelCHIMEI INNOLUX
model panelV420H2-LS2 Rev.C7
tipe panel a-Si TFT-LCD , LCM
ukuran panel42 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanSuper MVA, Normally Black, Transmissive
daerah aktif930.24×523.26 mm
garis besar968.4×564×27.7 mm
permukaanAntiglare (Haze 11%), Hard coating (3H)
kecerahan370 cd/m² (Typ.)
rasio kontras5000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon6 (Typ.)(G to G)
sudut pandang88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekuensi120Hz (60Hz Input)
jenis lampuWLEDEmbedded (LED Driver)
antarmuka sinyalLVDS (2 ch, 8-bit), 61 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
LC420EUF-SCA1 LG Display 42 1920×1080
LC420WUF-SBN1 LG Display 42 1920×1080
T420HW09 V1 AUO 42 1920×1080
V420H2-L01 Innolux 42 1920×1080
V420H2-L02 Innolux 42 1920×1080
V420H2-L05 Innolux 42 1920×1080
V420H2-LE3 Innolux 42 1920×1080
V420H2-LN1 Innolux 42 1920×1080
V420H2-LS1 Innolux 42 1920×1080
V420H2-LS2 Rev.C7 Innolux 42 1920×1080
