V420H2-L02

V420H2-L02
V420H2-L02
V420H2-L02 thumb V420H2-L02 thumb
Merek
Innolux
Ukuran
42
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
500
CR
3000:1
Warna
16.7M
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
2493
Spesifikasi

Nomor Bagian V420H2-L02
MerekInnolux
Ukuran42
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan500
CR3000:1
Warna16.7M
Lampu latarCCFL
AntarmukaLVDS
merek panelCHIMEI INNOLUX
model panelV420H2-L02
tipe panel a-Si TFT-LCD , LCM
ukuran panel42 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanSuper MVA, Normally Black, Transmissive
daerah aktif930.24×523.26 mm
garis besar983×576 mm
permukaanAntiglare (Haze 11%)
kecerahan500 cd/m² (Typ.)
rasio kontras3000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon8 (Typ.)(G to G)
sudut pandang88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekuensi60Hz
jenis lampu12 pcsCCFLWithout Driver
antarmuka sinyalLVDS (2 ch, 8-bit), 51 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
