Innolux V400H1-L03 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


V400H1-L03

V400H1-L03
V400H1-L03
V400H1-L03 thumb V400H1-L03 thumb
Merek
Innolux
Ukuran
40
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
500
CR
4000:1
Warna
16.7M
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
2476
Spesifikasi

Nomor Bagian V400H1-L03
MerekInnolux
Ukuran40
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan500
CR4000:1
Warna16.7M
Lampu latarCCFL
AntarmukaLVDS
merek panelCMO
model panelV400H1-L03
tipe panel a-Si TFT-LCD , LCM
ukuran panel40 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanMVA, Normally Black, Transmissive
daerah aktif885.6×498.15 mm
garis besar952×551 mm
permukaanAntiglare (Haze 17%), Hard coating (3H)
kecerahan500 cd/m² (Typ.)
rasio kontras4000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon6.5 (Typ.)(G to G)
sudut pandang88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekuensi60Hz
jenis lampu20 pcsCCFLEmbedded (Balance board)
antarmuka sinyalLVDS (2 ch, 8-bit), 51 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
V400H1-L01 Innolux 40 1920×1080
V400H1-L03 Innolux 40 1920×1080
V400H1-L05 Innolux 40 1920×1080
V400H1-L10 Innolux 40 1920×1080
V400H1-L11 Innolux 40 1920×1080
V400H1-LHA Innolux 40 1920×1080
V400HJ6-ME2 Innolux 40 1920×1080
V400HJ6-PE1 Innolux 40 1920×1080
V400HK2-LS5 Innolux 40 1920×1080
V400HK7-PE6 Innolux 40 1920×1080
