| Nomor Bagian | LTY400WS-L02 |
| Merek | Samsung |
| Ukuran | 40 |
| Aplikasi | LCTV |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 530 |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | S-LCD |
| model panel | LTY400WS-L02 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 40 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mode tampilan | S-PVA, Normally Black, Transmissive |
| daerah aktif | 885.168×497.664 mm |
| garis besar | 952×551×52 mm |
| permukaan | Antiglare (Haze 44%), Hard coating (3H) |
| kecerahan | 530 cd/m² (Typ.) |
| rasio kontras | 1200:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193172% |
| waktu merespon | 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 20 pcsCCFLEmbedded (Inverter) |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 41 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | LCTV |
| LTY400HA01 | Samsung | 40 | 1920×1080 |
| LTY400HC01 | Samsung | 40 | 1920×1080 |
| LTY400HC02 | Samsung | 40 | 1920×1080 |
| LTY400HF06 | Samsung | 40 | 1920×1080 |
| LTY400HL03 | Samsung | 40 | 1920×1080 |
| LTY400HM09 | Samsung | 40 | 1920×1080 |
| LTY400HM10 | Samsung | 40 | 1920×1080 |
| LTY400WS-L02 | Samsung | 40 | 1366×768 |
| V400HK2-LS5 | Innolux | 40 | 1920×1080 |
| LC420DUE-SFR3 | LG Display | 42 | 1920×1080 |
| LC550WUD-SBM4 | LG Display | 55 | 1920×1080 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| LTA230AP01 | Samsung | 23.0 | 1366×768 |
| LTA400HH-L02 | Samsung | 40 | 1920×1080 |
| MT5461D01-3 | CSOT | 55 | 3840×2160 |
| T260XW04 V7 | AUO | 26.0 | 1366×768 |
| T420HVF04.0 | AUO | 42 | 1920×1080 |
| V470H1-L08 | Innolux | 47 | 1920×1080 |
| V580DJ2-QS5 | Innolux | 58 | 3840×2160 |
