Innolux V370B1-L03 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com

V370B1-L03


Merek
Innolux
Ukuran
37
Aplikasi
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
450
CR
3000:1
Warna
16.7M
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
9140
Spesifikasi

Nomor Bagian V370B1-L03
MerekInnolux
Ukuran37
AplikasiLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan450
CR3000:1
Warna16.7M
Lampu latarCCFL
AntarmukaLVDS
merek panelCMO
model panelV370B1-L03
tipe panel a-Si TFT-LCD , LCM
ukuran panel37 inch
resolusi1366(RGB)×768 , WXGA
mode tampilanSuper MVA, Normally Black, Transmissive
daerah aktif819.6×460.8 mm
garis besar877×516.8 mm
permukaanAntiglare (Haze 11%), Hard coating (3H)
kecerahan450 cd/m² (Typ.)
rasio kontras3000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon6.5 (Typ.)(G to G)
sudut pandang88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekuensi60Hz
jenis lampu10 pcsCCFLEmbedded (Inverter)
antarmuka sinyalLVDS (1 ch, 8-bit), 30 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
