LG Display LC370WXN-SBD1 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


LC370WXN-SBD1

LC370WXN-SBD1
LC370WXN-SBD1
LC370WXN-SBD1 thumb LC370WXN-SBD1 thumb
Merek
LG Display
Ukuran
37
Aplikasi
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
1200:1
Warna
16.7M
Lampu latar
EEFL
Antarmuka
LVDS
In Stock
10781
Spesifikasi

Nomor Bagian LC370WXN-SBD1
MerekLG Display
Ukuran37
AplikasiLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR1200:1
Warna16.7M
Lampu latarEEFL
AntarmukaLVDS
merek panelLG Display
model panelLC370WXN-SBD1
tipe panel a-Si TFT-LCD , LCM
ukuran panel37 inch
resolusi1366(RGB)×768 , WXGA
mode tampilanS-IPS, Normally Black, Transmissive
daerah aktif819.6×460.8 mm
garis besar877×516.8 mm
permukaanAntiglare (Haze 10%), Hard coating (3H)
kecerahan500 cd/m² (Typ.)
rasio kontras1200:1 (Typ.)
menampilkan warna16.7M (8-bit)
waktu merespon5 (Typ.)(G to G)
sudut pandang89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampuEEFLEmbedded (Inverter)
antarmuka sinyalLVDS (1 ch, 8-bit), 30 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
LC370W01-A6 LG Display 37 1366×768
LC370WUD-SBM2 LG Display 37 1920×1080
LC370WUE-SBB2 LG Display 37 1920×1080
LC370WUG-SCA2 LG Display 37 1920×1080
LC370WUN-SAB1 LG Display 37 1920×1080
LC370WUN-SBD1 LG Display 37 1920×1080
LC370WUN-SCC1 LG Display 37 1920×1080
LC370WX1-SL01 LG Display 37 1366×768
LC370WX5-SLA1 LG Display 37 1366×768
LC370WXN-SBA1 LG Display 37 1366×768
