V260B1-L03

V260B1-L03
V260B1-L03
V260B1-L03 thumb V260B1-L03 thumb
Merek
Innolux
Ukuran
26.0
Aplikasi
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
800:1
Warna
16.2M
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
4045
Spesifikasi

Nomor Bagian V260B1-L03
MerekInnolux
Ukuran26.0
AplikasiLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR800:1
Warna16.2M
Lampu latarCCFL
AntarmukaLVDS
merek panelCMO
model panelV260B1-L03
tipe panel a-Si TFT-LCD , LCM
ukuran panel26.0 inch
resolusi1366(RGB)×768 , WXGA
mode tampilanTN, Normally White, Transmissive
daerah aktif575.769×323.712 mm
garis besar626×373 mm
permukaanAntiglare (Haze 25%), Hard coating (3H)
kecerahan500 cd/m² (Typ.)
rasio kontras800:1 (Typ.)
menampilkan warna16.2M (6-bit + FRC), CIE193172%
waktu merespon3/5 (Typ.)(Tr/Td)
sudut pandang80/80/80/70 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu12 pcsCCFLEmbedded (Inverter)
antarmuka sinyalLVDS (1 ch, 8-bit), 30 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
V260B1-L01 Innolux 26.0 1366×768
V260B1-L02 Innolux 26.0 1366×768
V260B1-L03 Innolux 26.0 1366×768
V260B1-L11 Innolux 26.0 1366×768
V260B2-L01 Innolux 26.0 1366×768
V260B2-L04 Innolux 26.0 1366×768
V260B3-L01 Innolux 26.0 1366×768
V260B3-L07 Innolux 26.0 1366×768
V260B3-LE1 Innolux 26.0 1366×768
V260B3-LE2 Innolux 26.0 1366×768
