| Nomor Bagian | LTY460HT-LH1 |
| Merek | Samsung |
| Ukuran | 46 |
| Aplikasi | LCTV |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 1700:1 |
| Warna | 1.07B |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | S-LCD |
| model panel | LTY460HT-LH1 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 46 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mode tampilan | SPVA, Normally Black, Transmissive |
| daerah aktif | 1018.08×572.67 mm |
| garis besar | 1083×627×57.1 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 1700:1 (Typ.) |
| menampilkan warna | 1.07B (10-bit), CIE193191% |
| waktu merespon | 10/6 (Typ.)(Tr/Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (Balance board) |
| antarmuka sinyal | LVDS (2 ch, 8-bit), 51 pins |
| tegangan masukan | 12.0V (Typ.) |
| aplikasi | LCTV |
