AUO T400HVN01.0 CELL lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


T400HVN01.0 CELL

T400HVN01.0 CELL
T400HVN01.0 CELL thumb
Merek
AUO
Ukuran
40
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
CELL
Kecerahan
0
CR
5000:1
Warna
16.7M
Lampu latar
No B/L
Antarmuka
LVDS
In Stock
19463
Spesifikasi

Nomor Bagian T400HVN01.0 CELL
MerekAUO
Ukuran40
AplikasiLCTV
Resolusi1920×1080
KomposisiCELL
Kecerahan0
CR5000:1
Warna16.7M
Lampu latarNo B/L
AntarmukaLVDS
merek panelAUO
model panelT400HVN01.0 CELL
tipe panel a-Si TFT-LCD , CELL
ukuran panel40 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanAMVA3, Normally Black, Transmissive
daerah aktif885.6×498.15 mm
permukaanAntiglare (Haze 2%)
kedalaman kaca0.50+0.50 mm
keterusan5.17% (Typ.)(with Polarizer)
rasio kontras5000:1 (Typ.)
menampilkan warna16.7M (6-bit + Hi-FRC)
waktu merespon3 (Typ.)(G to G)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
antarmuka sinyalLVDS (2 ch, 8-bit), 51 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
LTA400HF11 Samsung 40 1920×1080
LTA400HF30-W Samsung 40 1920×1080
LTA400HM09 Samsung 40 1920×1080
LTA400HV01 Samsung 40 1920×1080
LTY400HF06 Samsung 40 1920×1080
T400HVN01.0 CELL AUO 40 1920×1080
T400HW03 V0 AUO 40 1920×1080
T400HW03 V6 AUO 40 1920×1080
V400DK1-KE1 Innolux 40 3840×2160
V400HJ2-LE2 Innolux 40 1920×1080
