| Nomor Bagian | TV097FMM-LB0-1SP0 |
| Merek | BOE |
| Ukuran | 9.7 |
| Aplikasi | Pad & Tablet |
| Resolusi | 1280×1752 |
| Komposisi | a-Si TFT-LCD , Assem |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek | BOE |
| ukuran diagonal | 9.7 inch |
| format piksel | 1280(RGB)×1752 223PPI |
| daerah aktif | 145.344(H)×198.94(V) mm |
| daerah bezel | - |
| pencahayaan | 320 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| warna pendukung | 16.7M 70% NTSC |
| berat | 115g (Max.) |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | MIPI (4 data lanes) , 45 pins Connector |
| Sumber Daya listrik | 1.8/5.7/-5.7V (Typ.)(VDD/AVDD/AVEE) |
| lingkungan | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | TV097FMM-LB0-1SP0 |
| jenis | a-Si TFT-LCD , Assembly |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 150.344(H)×208.29(V) mm |
| perlakuan | Clear, Hard coating |
| rasio kontras | 1200:1 (Typ.) (TM) |
| waktu merespon | 35 (Max.)(G to G) |
| Modus operasi | - |
| sumber cahaya | WLED [9S4P] , 15K hours , W/O Driver |
| dirancang untuk | Pad & Tablet |
| panel sentuh | In-Cell Touch |
