| Nomor Bagian | TV070WXM-NS0 |
| Merek | BOE |
| Ukuran | 7.0 |
| Aplikasi | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | 5S4P |
| Antarmuka | MIPI |
| pabrikan | BOE |
| nama model | TV070WXM-NS0 |
| ukuran layar | 7.0 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 800(RGB)×1280 (WXGA) 215PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 94.2 × 150.72 (H×V) |
| garis besar (mm) | 99.7 × 160.93 × 3.8 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Hard coating (3H), Antireflection |
| pencahayaan | 450 cd/m² (Typ.) |
| rasio kontras | 900 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | 5S4P WLED , 20K hours , No Driver |
| massa | 74.5g (Typ.) |
| digunakan untuk | Pad & Tablet |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | MIPI (4 data lanes) , 34 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: -20 ~ 60 °C |
