| Nomor Bagian | TM101JDHG33 |
| Merek | TIANMA |
| Ukuran | 10.1 |
| Aplikasi | Industrial Medical I |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | TIANMA |
| ukuran diagonal | 10.1 inch |
| format piksel | 1280(RGB)×800 [WXGA] 149PPI |
| daerah aktif | 216.96(H)×135.6(V) mm |
| daerah bezel | 219.96(H)×138.6(V) mm |
| pencahayaan | 900 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| warna pendukung | 262K/16.7M 50% NTSC |
| berat | 280g (Typ.) |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 80 °C |
| model | TM101JDHG33 |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 229.8(H)×149(V) ×9.6(D) mm |
| perlakuan | Hard coating |
| rasio kontras | 700:1 (Typ.) (TM) |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| Modus operasi | SFT, Normally Black, Transmissive |
| sumber cahaya | WLED , 40K hours , With LED Driver |
| dirancang untuk | Industrial Medical Imaging Outdoor High Brightness |
| panel sentuh | Without |
