| Nomor Bagian | TM101DDHG05 |
| Merek | TIANMA |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | TIANMA |
| ukuran diagonal | 10.1 inch |
| format piksel | 1024(RGB)×600 [WSVGA] 117PPI |
| daerah aktif | 222.72(H)×125.28(V) mm |
| daerah bezel | - |
| pencahayaan | 1400 cd/m² (Typ.) |
| arah pandangan | 12 o'clock |
| sudut pandang | 80/80/75/80 (Typ.)(CR≥10) |
| warna pendukung | 262K/16.7M 47% NTSC |
| berat | - |
| kecepatan bingkai | 60Hz |
| model | TM101DDHG05 |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 235(H)×143(V) ×7.8(D) mm |
| perlakuan | Antiglare, Hard coating |
| rasio kontras | 500:1 (Typ.) (TM) |
| waktu merespon | 7/9 (Typ.)(Tr/Td) |
| Modus operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED [14S3P] , 30K hours , W/O Driver |
| dirancang untuk | Industrial |
| panel sentuh | Without |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| BT101IW02 V.0 | Innolux | 10.1 | 1024×600 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
