| Nomor Bagian | TM080RDHP07 |
| Merek | TIANMA |
| Ukuran | 8.0 |
| Aplikasi | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| merek | TIANMA |
| ukuran diagonal | 8.0 inch |
| format piksel | 800(RGB)×480 [WVGA] 116PPI |
| daerah aktif | 174(H)×104.4(V) mm |
| daerah bezel | 177(H)×107.4(V) mm |
| pencahayaan | 600 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10) |
| warna pendukung | 16.7M 71% NTSC |
| berat | TBD |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | Parallel RGB (1 ch, 8-bit) , 60 pins FPC |
| Sumber Daya listrik | 3.3/6.0/-6.0/17/-8V (Typ.)(VCC/VDDP/VDDN/VGH/VGL) |
| lingkungan | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| model | TM080RDHP07 |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 190.4(H)×120.7(V) ×16.1(D) mm |
| perlakuan | Antiglare |
| rasio kontras | 1000:1 (Typ.) (TM) |
| waktu merespon | 50 (Max.)(Tr+Td) |
| Modus operasi | SFT, Normally Black, Transmissive |
| sumber cahaya | WLED [8S2P] , 20K hours , W/O Driver |
| dirancang untuk | Automotive Display |
| panel sentuh | Without |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080WQ05 | CPT | 8.0 | 800×1280 |
| TM080SDH01 | Tianma | 8.0 | 800×600 |
| TM080SV-04L01 | SANYO | 8.0 | 800×600 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| TM080XPH01 | Tianma | 8.0 | 1280×768 |
| ZJ080NA-08A | Innolux | 8.0 | 1024×600 |
