| Nomor Bagian | TM050RDZG03-30 |
| Merek | TIANMA |
| Ukuran | 5.0 |
| Aplikasi | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | 3S6P |
| Antarmuka | |
| pabrikan | TIANMA |
| nama model | TM050RDZG03-30 |
| ukuran layar | 5.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 800(RGB)×480 (WVGA) 188PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 108 × 64.8 (H×V) |
| garis besar (mm) | 120.7 × 77.8 × 5.9 (H×V×D) |
| area bezel (mm) | 111.1 × 67.9 (H×V) |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 1000 cd/m² (Typ.) |
| rasio kontras | 600 : 1 (Typ.) (TM) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| tanggapan | 20/30 (Typ./Max.)(Tr+Td) ms |
| pemandangan bagus di | 12 o'clock |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | 3S6P WLED , 50K hours |
| massa | TBD |
| digunakan untuk | Industrial |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
