| Nomor Bagian | DLC0500AIG-2 |
| Merek | Other |
| Ukuran | 5.0 |
| Aplikasi | VDP |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | DLC |
| model panel | DLC0500AIG-2 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 5.0 inch |
| resolusi | 640(RGB)×480 , VGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 101.568×76.176 mm |
| garis besar | 117.65×88.43×6 mm |
| permukaan | Antiglare |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) |
| menampilkan warna | 262K (6-bit), CIE193140% |
| waktu merespon | 10/10 (Typ.)(Tr/Td) |
| sudut pandang | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 3S6PWLEDWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit), 40 pins |
| tegangan masukan | 3.3V (Typ.)(VCC) |
| aplikasi | VDP |
