| Nomor Bagian | TM024HDHG04 |
| Merek | TIANMA |
| Ukuran | 2.4 |
| Aplikasi | Handheld & PDA |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | - |
| Lampu latar | WLED |
| Antarmuka | CPU |
| merek panel | TIANMA |
| model panel | TM024HDHG04 |
| ukuran panel | 2.4" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 240(RGB)×320, QVGA, 166PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 36.72(W)×48.96(H) mm |
| bukaan bezel | - |
| kecerahan | - |
| rasio kontras | 500:1 (Typ.) (TM) |
| sudut pandang | 70/70/70/60 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | - |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| menampilkan warna | |
| jenis lampu | WLED |
| frekuensi | - |
| layar sentuh | Without |
| berat panel | - |
| aplikasi | Handheld & PDA |
| antarmuka sinyal | CPU FPC |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
