| Nomor Bagian | TCG121XGLPBPNN-AN40-S |
| Merek | Kyocera |
| Ukuran | 12.1 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | Kyocera |
| model panel | TCG121XGLPBPNN-AN40-S |
| ukuran panel | 12.1" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×768, XGA, 105PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 245.76(W)×184.32(H) mm |
| bukaan bezel | 249.0(W)×187.5(H) mm |
| ukuran garis besar | 260.5(W)×203(H) ×10.9(D) mm |
| permukaan | Antiglare |
| kecerahan | 780 cd/m² (Typ.) |
| rasio kontras | 600:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | AWV, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 18/12 (Typ.)(Tr/Td) |
| menampilkan warna | 262K/16.2M 51% NTSC |
| jenis lampu | WLED , 50K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 555g |
| aplikasi | Industrial Outdoor High Brightness |
| antarmuka sinyal | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| AA121SJ23 | Mitsubishi | 12.1 | 800×600 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| HV121WX5-113 | HYDIS | 12.1 | 1280×800 |
| LQ121S1DC71 | SHARP | 12.1 | 800×600 |
| LQ121X1LH73 | SHARP | 12.1 | 1024×768 |
| LTD121C32S | TOSHIBA | 12.1 | 800×600 |
| LTD121EA3P | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXPD | TOSHIBA | 12.1 | 1280×800 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
