| Nomor Bagian | TCG101WXLPAANN-AN20-SA |
| Merek | Kyocera |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | Kyocera |
| model panel | TCG101WXLPAANN-AN20-SA |
| ukuran panel | 10.1" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1280(RGB)×800, WXGA, 149PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 216.96(W)×135.6(H) mm |
| bukaan bezel | 219.96(W)×138.6(H) mm |
| ukuran garis besar | 236(W)×156.8(H) ×9.9(D) mm |
| permukaan | Antiglare |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | - |
| waktu merespon | 8/22 (Typ.)(Tr/Td) |
| menampilkan warna | 16.2M 52% NTSC |
| jenis lampu | WLED , 50K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 500g (Typ.) |
| aplikasi | Industrial |
| antarmuka sinyal | LVDS (1 ch, 8-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| B101EAN01.3 | AUO | 10.1 | 1280×800 |
| B101EAN01.5 | AUO | 10.1 | 1280×800 |
| B101EAN01.6 | AUO | 10.1 | 1280×800 |
| B101EW02 V1 | AUO | 10.1 | 1280×720 |
| DLC1010DZG-T-8 | Other | 10.1 | 1280×800 |
| LP101WX1-SLB1 | LG Display | 10.1 | 1280×800 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| M101MWW4 R0 | IVO | 10.1 | 1024×600 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
