AUO T650HVN07.3 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


T650HVN07.3

T650HVN07.3
T650HVN07.3
T650HVN07.3
T650HVN07.3 thumb T650HVN07.3 thumb T650HVN07.3 thumb
Merek
AUO
Ukuran
65
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
350
CR
4000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
6204
Spesifikasi

Nomor Bagian T650HVN07.3
MerekAUO
Ukuran65
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan350
CR4000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
merek panelAUO
model panelT650HVN07.3
tipe panel a-Si TFT-LCD , LCM
ukuran panel65 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanAMVA3, Normally Black, Transmissive
daerah aktif1428.48×803.52 mm
garis besar1454.3×831.5×33.6 mm
permukaanAntiglare (Haze 2%), Hard coating (3H)
kecerahan350 cd/m² (Typ.)
rasio kontras4000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon6.5(Typ.)(G to G)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampuWLEDEmbedded (LED Driver)
antarmuka sinyalLVDS (2 ch, 8-bit), 51 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
T650HVD01.0 AUO 65 1920×1080
T650HVF03.0 AUO 65 1920×1080
T650HVJ02.0 AUO 65 1920×1080
T650HVJ02.1 AUO 65 1920×1080
T650HVN04.0 AUO 65 1920×1080
T650HVN04.1 AUO 65 1920×1080
T650HVN05.4 AUO 65 1920×1080
T650HVN05.9 AUO 65 1920×1080
T650HVN06.0 AUO 65 1920×1080
T650HVN07.3 AUO 65 1920×1080
