AUO T420HVN08.0 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


T420HVN08.0

T420HVN08.0
T420HVN08.0 thumb
Merek
AUO
Ukuran
42
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
400
CR
3000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
367
Spesifikasi

Nomor Bagian T420HVN08.0
MerekAUO
Ukuran42
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan400
CR3000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
merek panelAUO
model panelT420HVN08.0
tipe panel a-Si TFT-LCD , LCM
ukuran panel42 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanAMVA3, Normally Black, Transmissive
daerah aktif930.24×523.26 mm
garis besar952.2×547×27.9 mm
permukaanAntiglare (Haze 2%), Hard coating (3H)
kecerahan400 cd/m² (Typ.)
rasio kontras3000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon6.5 (Typ.)(G to G)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampuWLEDEmbedded (LED Driver)
antarmuka sinyalLVDS (2 ch, 8-bit), 51 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
T420HVN01.0 AUO 42 1920×1080
T420HVN04.0 CELL AUO 42 1920×1080
T420HVN04.5 CELL AUO 42 1920×1080
T420HW01 V2 AUO 42 1920×1080
T420HW04 V0 AUO 42 1920×1080
T420HW05 V3 AUO 42 1920×1080
T420HW06 V5 AUO 42 1920×1080
T420HW07 V0 AUO 42 1920×1080
T420HW07 V1 AUO 42 1920×1080
T420HW09 V1 AUO 42 1920×1080
