T320XW04 V3 CELL

T320XW04 V3 CELL
T320XW04 V3 CELL thumb
Merek
AUO
Ukuran
31.5
Aplikasi
LCTV
Resolusi
1366×768
Komposisi
CELL
Kecerahan
0
CR
3000:1
Warna
16.7M
Lampu latar
No B/L
Antarmuka
LVDS
In Stock
1
Spesifikasi

Nomor Bagian T320XW04 V3 CELL
MerekAUO
Ukuran31.5
AplikasiLCTV
Resolusi1366×768
KomposisiCELL
Kecerahan0
CR3000:1
Warna16.7M
Lampu latarNo B/L
AntarmukaLVDS
merek panelAUO
model panelT320XW04 V3 CELL
tipe panel a-Si TFT-LCD , CELL
ukuran panel31.5 inch
resolusi1366(RGB)×768 , WXGA
mode tampilanMVA, Normally Black, Transmissive
daerah aktif697.685×392.256 mm
garis besar716.1×408.7 mm
permukaanAntiglare (Haze 2%), Hard coating (3H)
rasio kontras3000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon6.5 (Typ.)(G to G)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
antarmuka sinyalLVDS (1 ch, 8-bit), 30 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
