T315XW02 VF

T315XW02 VF
T315XW02 VF
T315XW02 VF
T315XW02 VF thumb T315XW02 VF thumb T315XW02 VF thumb
Merek
AUO
Ukuran
31.5
Aplikasi
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
1800:1
Warna
16.7M
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
14148
Spesifikasi

Nomor Bagian T315XW02 VF
MerekAUO
Ukuran31.5
AplikasiLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR1800:1
Warna16.7M
Lampu latarCCFL
AntarmukaLVDS
merek panelAUO
model panelT315XW02 VF
tipe panel a-Si TFT-LCD , LCM
ukuran panel31.5 inch
resolusi1366(RGB)×768 , WXGA
mode tampilanAMVA, Normally Black, Transmissive
daerah aktif697.685×392.256 mm
garis besar760×450 mm
permukaanAntiglare, Hard coating (3H)
kecerahan500 cd/m² (Typ.)
rasio kontras1800:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon5.5 (Typ.)(G to G)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi120Hz (60Hz Input)
jenis lampuCCFLEmbedded (Inverter)
antarmuka sinyalLVDS (2 ch, 8-bit), 51 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
T315XW02 VF AUO 31.5 1366×768
T315XW02 VT AUO 31.5 1366×768
T315XW02 VV AUO 31.5 1366×768
T315XW03 V4 AUO 31.5 1366×768
T315XW03 VD AUO 31.5 1366×768
T315XW04 V0 AUO 31.5 1366×768
T315XW04 V1 AUO 31.5 1366×768
T315XW06 V0 AUO 31.5 1366×768
T315XW06 V6 AUO 31.5 1366×768
T315XW07 V2 AUO 31.5 1366×768
