| Nomor Bagian | T-55692D070H-LW-A-AAN |
| Merek | Kyocera |
| Ukuran | 7.0 |
| Aplikasi | IA |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 1000 |
| CR | 1000:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | OPTREX |
| model panel | T-55692D070H-LW-A-AAN 1 Compatible model |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mode tampilan | IPS, Normally Black, Transmissive |
| daerah aktif | 152.4×91.44 mm |
| garis besar | 169.8×109.7×9.4 mm |
| permukaan | Clear, Hard coating (3H) |
| kecerahan | 1000 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) |
| menampilkan warna | 262K/16.7M (6-bit / 8-bit), CIE193150% |
| waktu merespon | 12/12 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | LVDS (1 ch, 6/8-bit), 20 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | IA |
