| Nomor Bagian | STCG057QVLAD-G00 |
| Merek | Kyocera |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| pabrikan | Kyocera |
| nama model | STCG057QVLAD-G00 |
| ukuran layar | 5.7 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 320(RGB)×240 (QVGA) 70PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 115.2 × 86.4 (H×V) |
| garis besar (mm) | - |
| area bezel (mm) | - |
| perlakuan | Glare (Haze 0%) |
| pencahayaan | - |
| rasio kontras | 500 : 1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥5) |
| tanggapan | 10/25 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | - |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K |
| lampu latar | WLED |
| massa | - |
| digunakan untuk | Industrial |
| tingkat penyegaran | - |
| layar sentuh | 4-wire Resistive Touch |
| jenis sinyal | Parallel RGB (1 ch, 6-bit) |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
