| Nomor Bagian | SG2701B01-3 |
| Merek | CSOT |
| Ukuran | 27.0 |
| Aplikasi | Desktop Monitor Gami |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 4000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| merek | CSOT |
| model | SG2701B01-3 |
| ukuran diagonal | 27.0 inch |
| jenis | a-Si TFT-LCD, CELL |
| format piksel | 1920(RGB)×1080 [FHD] 81PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 597.888(H)×336.312(V) mm |
| garis besar redup. | 608.888(H)×348.337(V) ×1.3(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare (Haze 25%) |
| pencahayaan | 0 cd/m² |
| rasio kontras | 4000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 12 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| Modus operasi | HVA, Normally Black, Transmissive |
| ketebalan pelat | 0.40+0.50 mm |
| transmisi | 4.6% (Typ.)(with Polarizer) |
| warna pendukung | 16.7M 99% sRGB |
| sumber cahaya | No B/L |
| berat | - |
| dirancang untuk | Desktop Monitor Gaming |
| kecepatan bingkai | 165Hz |
| panel sentuh | Without |
| detail d-ic | COF Built-in 6 source chips |
| tipe antarmuka | LVDS (4 ch, 8-bit) , 61 pins Connector |
| Sumber Daya listrik | 12.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
