M270HHF-L10

M270HHF-L10
M270HHF-L10
M270HHF-L10
M270HHF-L10 thumb M270HHF-L10 thumb M270HHF-L10 thumb
Merek
Innolux
Ukuran
27.0
Aplikasi
DMPC
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
300
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
12067
Spesifikasi

Nomor Bagian M270HHF-L10
MerekInnolux
Ukuran27.0
AplikasiDMPC
Resolusi1920×1080
KomposisiLCM
Kecerahan300
CR1000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
merek panelCHIMEI INNOLUX
model panelM270HHF-L10
tipe panel a-Si TFT-LCD , LCM
ukuran panel27.0 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanTN, Normally White, Transmissive
daerah aktif597.888×336.312 mm
garis besar630×368.2×16.4 mm
permukaanAntiglare (Haze 25%), Hard coating (3H)
kecerahan300 cd/m² (Typ.)
rasio kontras1000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon0.8/2.6 (Typ.)(Tr/Td)
sudut pandang85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
frekuensi120Hz
jenis lampu4 stringsWLEDWithout Driver
antarmuka sinyalLVDS (4 ch, 8-bit), 92 pins
tegangan masukan12.0V (Typ.)
aplikasiDMPC
