| Nomor Bagian | M270HW02 V1 |
| Merek | AUO |
| Ukuran | 27.0 |
| Aplikasi | DMPC |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 5000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | AUO |
| model panel | M270HW02 V1 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 27.0 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mode tampilan | MVA, Normally Black, Transmissive |
| daerah aktif | 597.6×336.15 mm |
| garis besar | 630×368.2×12 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 5000:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193172% |
| waktu merespon | 7/5 (Typ.)(Tr/Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 18S4PWLEDWithout Driver |
| antarmuka sinyal | LVDS (2 ch, 8-bit), 30 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
