| Nomor Bagian | PV156FHM-T00 |
| Merek | BOE |
| Ukuran | 15.6 |
| Aplikasi | Industrial |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, Assemb |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek | BOE |
| model | PV156FHM-T00 (BOE083E) |
| ukuran diagonal | 15.6 inch |
| jenis | a-Si TFT-LCD, Assembly |
| format piksel | 1920(RGB)×1080 [FHD] 141PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 344.16(H)×193.59(V) mm |
| garis besar redup. | 361(H)×223(V) mm |
| daerah bezel | - |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 400 cd/m² (Min.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | - |
| warna pendukung | 16.7M 45% NTSC |
| sumber cahaya | WLED [11S4P] , 30K hours , With LED Driver |
| berat | 670g (Max.) |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | On-Cell Touch |
| tipe antarmuka | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 40 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
