| Nomor Bagian | M156B1-L01 |
| Merek | Innolux |
| Ukuran | 15.6 |
| Aplikasi | DMPC |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | CMO |
| model panel | M156B1-L01 4 Compatible model |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 15.6 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 344.232×193.536 mm |
| garis besar | 363.8×215.9×14.8 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC), CIE193165% |
| waktu merespon | 2/6 (Typ.)(Tr/Td) |
| sudut pandang | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 30 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
| B156HW01 V3 | AUO | 15.6 | 1920×1080 |
| HB156WX1-100 | BOE | 15.6 | 1366×768 |
| LP156WF4-SPH3 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TLD1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLG1 | LG Display | 15.6 | 1366×768 |
| LTN156AT11-A01 | Samsung | 15.6 | 1366×768 |
| LTN156AT35-W01 | Samsung | 15.6 | 1366×768 |
| M156B1-L01 | Innolux | 15.6 | 1366×768 |
| M156B1-L02 | Innolux | 15.6 | 1366×768 |
| M156B3-L01 | Innolux | 15.6 | 1366×768 |
| LM190WX1-TLL1 | LG Display | 19.0 | 1440×900 |
| LM215DT1A | PANDA | 21.5 | 1920×1080 |
| LM220WE5-TLA1 | LG Display | 22.0 | 1680×1050 |
| LM230WF2-SLA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLD2 | LG Display | 23.0 | 1920×1080 |
| LTM190E4-L02 | Samsung | 19.0 | 1280×1024 |
| LTM240CS09 | Samsung | 24.0 | 1920×1200 |
| LTM340YP01 | Samsung | 34 | 3440×1440 |
| M200HJJ-P01 | Innolux | 19.5 | 1920×1080 |
| M201EW02 V6 | AUO | 20.1 | 1680×1050 |
