| Nomor Bagian | NV156FHM-N4N |
| Merek | BOE |
| Ukuran | 15.6 |
| Aplikasi | Laptop Gaming |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | 8S6P |
| Antarmuka | eDP |
| merek panel | BOE |
| ukuran panel | 15.6" |
| resolusi | 1920(RGB)×1080, FHD, 141PPI |
| area tampilan | 344.16(W)×193.59(H) mm |
| ukuran garis besar | 350.66(W)×216.25(H) ×3.2(D) mm |
| kecerahan | 300 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 72% NTSC |
| frekuensi | 144Hz |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| antarmuka sinyal | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | NV156FHM-N4N (BOE084A) |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare (Haze 25%) |
| rasio kontras | 1200:1 (Typ.) (TM) |
| mode tampilan | HADS, Normally Black, Transmissive |
| waktu merespon | 9 (Typ.)(Tr+Td); 7 (Typ.)(G to G) |
| jenis lampu | 8S6P WLED , 15K hours , With LED Driver |
| layar sentuh | Without |
| aplikasi | Laptop Gaming |
