| Nomor Bagian | NV156FHM-A12 |
| Merek | BOE |
| Ukuran | 15.6 |
| Aplikasi | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | Assembly , a-Si TF |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | 8S5P |
| Antarmuka | eDP |
| pabrikan | BOE |
| ukuran layar | 15.6 inch |
| nomor piksel | 1920(RGB)×1080 (FHD) 141PPI |
| area aktif (mm) | 344.16 × 193.59 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 230 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 262K 45% NTSC |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | eDP (2 Lanes) , 30 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | NV156FHM-A12 (BOE065E) |
| tipe layar | Assembly , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 374.9 × 236.4 × 4.2 (H×V×D) |
| perlakuan | Anti-Scatter, Hard coating (9H), Antireflection |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| mode kerja | - |
| lampu latar | 8S5P WLED , 15K hours , With LED Driver |
| digunakan untuk | Laptop |
| layar sentuh | PCAP, Optical Bonding |
| B156XTK01.0 | AUO | 15.6 | 1366×768 |
| CLAA156WB11A | CPT | 15.6 | 1366×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LP156WF1-TLE1 | LG Display | 15.6 | 1920×1080 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LP156WHB-TPD1 | LG Display | 15.6 | 1366×768 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
| SVA156WX1-01TB | SVA-NEC | 15.6 | 1366×768 |
