| Nomor Bagian | NV140FHM-T01 |
| Merek | BOE |
| Ukuran | 14.0 |
| Aplikasi | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | 8S4P |
| Antarmuka | |
| pabrikan | BOE |
| ukuran layar | 14.0 inch |
| nomor piksel | 1920(RGB)×1080 (FHD) 157PPI |
| area aktif (mm) | 309.31 × 173.99 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 250 (Typ.)(cd/m²) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 262K 45% NTSC |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| tingkat penyegaran | 60Hz |
| nama model | NV140FHM-T01 (BOE07EF) |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 315.81 × 197.48 × 3.2 (H×V×D) |
| perlakuan | Antiglare, Hard coating (3H) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| mode kerja | ADS, Normally Black, Transmissive |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| lampu latar | 8S4P WLED , 15K hours , With LED Driver |
| digunakan untuk | Laptop |
| layar sentuh | On-Cell Touch |
| B140HAN01.1 | AUO | 14.0 | 1920×1080 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| B140RTN01.0 | AUO | 14.0 | 1600×900 |
| B140XTN03.2 | AUO | 14.0 | 1366×768 |
| B140XTN03.3 HW0A | AUO | 14.0 | 1366×768 |
| HSD140PNW1-B00 | HannStar | 14.0 | 1600×900 |
| HT140WXB-501 | BOE | 14.0 | 1366×768 |
| HW14WX101 | BOE | 14.0 | 1366×768 |
| N140BGK-L33 | Innolux | 14.0 | 1366×768 |
| NV140FHM-N41 | BOE | 14.0 | 1920×1080 |
