| Nomor Bagian | NV101WUM-N52 |
| Merek | BOE |
| Ukuran | 10.1 |
| Aplikasi | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| pabrikan | BOE |
| ukuran layar | 10.1 inch |
| nomor piksel | 1200(RGB)×1920 (WUXGA) 225PPI |
| area aktif (mm) | 135.36 × 216.576 (H×V) |
| pencahayaan | 400 cd/m² (Typ.) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M 68% NTSC |
| massa | 132g (Typ.) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | MIPI (4 data lanes) , 42 pins Connector |
| sumber tegangan | 1.8/3.3V (Typ.)(VDD1/VDD3) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | NV101WUM-N52 |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 141.56 × 228.226 × 4.2 (H×V×D) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| tanggapan | 35 (Max.)(Tr+Td) ms |
| mode kerja | ADS, Normally Black, Transmissive |
| lampu latar | WLED , 15K hours , No Driver |
| digunakan untuk | Pad & Tablet |
| layar sentuh | Without |
