| Nomor Bagian | NT125WHM-N42 |
| Merek | BOE |
| Ukuran | 12.5 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 9S3P |
| Antarmuka | eDP |
| pabrikan | BOE |
| nama model | NT125WHM-N42 (BOE06C8) |
| ukuran layar | 12.5 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1366(RGB)×768 (WXGA) 125PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 276.615 × 155.52 (H×V) |
| garis besar (mm) | 290.5 × 180.9 × 3 (H×V×D) |
| pencahayaan | 200 cd/m² (Typ.) |
| rasio kontras | 500 : 1 (Typ.) (TM) |
| sudut pandang | 45/45/20/40 (Typ.)(CR≥10) |
| tanggapan | 8 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | 6 o'clock |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K 45% NTSC |
| lampu latar | 9S3P WLED , 15K hours , With LED Driver |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| digunakan untuk | Laptop |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | eDP (2 Lanes) , eDP1.2 , Connector 40 pins |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
