| Nomor Bagian | B125HAN02.2 |
| Merek | AUO |
| Ukuran | 12.5 |
| Aplikasi | NBPC |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | AUO |
| model panel | B125HAN02.2 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 12.5 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mode tampilan | AHVA, Normally Black, Transmissive |
| daerah aktif | 276.48×155.52 mm |
| garis besar | 282.4×179.32×2.5 mm |
| gaya bentuk | Slim (PCBA Flat, Depth ≤3.2mm) |
| permukaan | Antiglare |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 700:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193150% |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | eDP (2 Lanes), 30 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | NBPC |
| B125HAN01.0 | AUO | 12.5 | 1920×1080 |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| B125HAN02.2 | AUO | 12.5 | 1920×1080 |
| B125XW01 V0 | AUO | 12.5 | 1366×768 |
| HB125WX1-100 | BOE | 12.5 | 1366×768 |
| LP125WF1-SPD1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB3 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LTN125AT03-803 | Samsung | 12.5 | 1366×768 |
| M125NWR2 R1 | IVO | 12.5 | 1366×768 |
| B133XW04 V0 | AUO | 13.3 | 1366×768 |
| BT156GW01 V.4 | Innolux | 15.6 | 1366×768 |
| LP133WH2-TLL3 | LG Display | 13.3 | 1366×768 |
| LP140WD1-TLM1 | LG Display | 14.0 | 1600×900 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLM2 | LG Display | 14.0 | 1366×768 |
| LTN140AT21-T01 | Samsung | 14.0 | 1366×768 |
| LTN141XF-L03 | Samsung | 14.1 | 1024×768 |
| LTN156KT01-W01 | Samsung | 15.6 | 1600×900 |
| N141I6-D11 | Innolux | 14.1 | 1280×800 |
