| Nomor Bagian | NL6448AC33-A1D |
| Merek | NLT |
| Ukuran | 10.4 |
| Aplikasi | Industrial |
| Resolusi | 640×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | |
| pabrikan | NLT |
| nama model | NL6448AC33-A1D |
| ukuran layar | 10.4 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 640(RGB)×480 (VGA) 76PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 211.2 × 158.4 (H×V) |
| garis besar (mm) | 227.3 × 177.5 × 9.8 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Antiglare |
| pencahayaan | 370 cd/m² (Typ.) |
| rasio kontras | 900 : 1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tanggapan | 18 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | - |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K |
| lampu latar | WLED , 100K hours , With LED Driver |
| massa | 380g (Max.) |
| digunakan untuk | Industrial |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
