| Nomor Bagian | NL10276AC30-07 |
| Merek | NLT |
| Ukuran | 15.0 |
| Aplikasi | DMPC |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 300:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antarmuka | TTL |
| merek panel | NEC |
| model panel | NL10276AC30-07 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 15.0 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mode tampilan | Normally Black, Transmissive |
| daerah aktif | 304.128×228.096 mm |
| garis besar | 330×256×30 mm |
| permukaan | Hard coating (2H) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 300:1 (Typ.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC), CIE193160% |
| waktu merespon | 10/10 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 8 pcsCCFLEmbedded (Inverter) |
| antarmuka sinyal | TTL (2 ch, 8-bit), 75 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
