| Nomor Bagian | NE156QUM-N64 |
| Merek | BOE |
| Ukuran | 15.6 |
| Aplikasi | Laptop |
| Resolusi | 3840×2160 |
| Komposisi | Oxide TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 10S6P |
| Antarmuka | eDP |
| merek panel | BOE |
| ukuran panel | 15.6" |
| resolusi | 3840(RGB)×2160, UHD, 283PPI |
| area tampilan | 344.218(W)×193.622(H) mm |
| ukuran garis besar | 350.52(W)×205.92(H) ×4.6(D) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 72% NTSC |
| frekuensi | 60Hz |
| gaya bentuk | Slim (PCBA Bent, T≤3.0mm) |
| antarmuka sinyal | eDP (4 Lanes) , eDP1.4a , HBR2 (5.4G/lane) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | NE156QUM-N64 (BOE07D9) |
| tipe panel | Oxide TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | ADS, Normally Black, Transmissive |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| jenis lampu | 10S6P WLED , 15K hours , With LED Driver |
| layar sentuh | Without |
| aplikasi | Laptop |
