| Nomor Bagian | M240UW01 V2 |
| Merek | AUO |
| Ukuran | 24.0 |
| Aplikasi | DMPC |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 470 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | AUO |
| model panel | M240UW01 V2 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 24.0 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mode tampilan | AMVA, Normally Black, Transmissive |
| daerah aktif | 518.4×324 mm |
| garis besar | 546.4×352×36.3 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 470 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193172% |
| waktu merespon | 10/6 (Typ.)(Tr/Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 6 pcsCCFLWithout Driver |
| antarmuka sinyal | LVDS (2 ch, 8-bit), 30 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
| LM190E05-SL02 | LG Display | 19.0 | 1280×1024 |
| LM195WD1-TLA1 | LG Display | 19.5 | 1600×900 |
| LM201WE3-TLJ3 | LG Display | 20.1 | 1680×1050 |
| LM215WF3-SDD1 | LG Display | 21.5 | 1920×1080 |
| LM270WF4-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM300WQ6-SLA1 | LG Display | 30.0 | 2560×1600 |
| LTM185AT04 | Samsung | 18.5 | 1366×768 |
| M220EW01 V2 | AUO | 22.0 | 1680×1050 |
| NL10276AC30-07 | NLT | 15.0 | 1024×768 |
| TMS190WX1-05TB | Tianma | 19.0 | 1440×900 |
